Making Unsedated Endoscopy a Reality!

EvoEndo® Model LE Single-Use
Gastroscope + EvoEndo® Controller

Note: US: Rx Only. For use by trained physicians only.

Making Unsedated Endoscopy a Reality!

EvoEndo® Model LE Single-Use Gastroscope + EvoEndo® Controller

Note: US: Rx Only. For use by trained physicians only.

EvoEndo addresses critical clinical needs in endoscopy.

HD image

The high definition camera in the EvoEndo Scope provides unparalleled visualization when compared to other single-use scopes, and has demonstrated comparable image quality to the market leaders in reusable endoscopes.

3.5 mm outer diameter

Existing transnasal gastroscopes have an outer diameter that is too large for many adults, making them inappropriate for unsedated pediatric use. The EvoEndo Scope’s 3.5 mm outer diameter is small enough for almost all noses, and does not require anesthesia or sedation during a diagnostic upper endoscopy.

1.1 m length

The length of the EvoEndo scope allows for evaluation and treatment. It is the only scope that can do a full pediatric transnasal upper GI exam.

2 mm working channel

The 2 mm working channel on the EvoEndo Scope accommodates standard and affordable pediatric biopsy forceps. Existing endoscopes with a smaller outer diameter often have a smaller channel requiring specialized and expensive forceps, driving up the cost of the procedure for hospitals and patients.

Sterile single-use

The risk of infection from contaminated endoscopes even after reprocessing is a significant concern. The FDA continues to urge scope manufacturers to move toward disposable components or completely disposable systems to mitigate this risk. The EvoEndo Scope is one-time-use, making it safer for patients and more efficient for hospitals and physicians by eliminating the risk of infection.

4-way steering

The EvoEndo Scope has 4-way deflection capabilities, allowing physicians to perform a complete unsedated examination of the esophagus, stomach, and small intestine with a 120° field of view. The mirrored left/right wheels on the EvoEndo scope allow ambidextrous navigation, and the hybrid up/down thumb trigger provides intuitive steering when navigating complex anatomy.

Integrated air, water, and suction lines & connectors

EvoEndo’s integrated air, water, and suction standard connectors make it simple to set up and start using our scope. The activation buttons on the scope handle allow physicians to quickly and easily administer air, water, and suction during a procedure to ensure optimal lens cleaning and visualization of the target anatomy.

EvoEndo Controller

The EvoEndo Controller processes the video and image feed from the scope camera, and allows direct HDMI or USB output to any medical monitor or computer system. Our Controller can be easily configured to work with industry standard endoscopy reporting software. At just 6×8″, it is ultra portable and quick to clean after each procedure.
